Taylor-Dunn MX 1600 - Page 223

Illustrated Parts
PARTS PAGE 39
Seat Cushions, Deck and Lights, MX 1600
ITEM # PART # DESCRIPTION QTY
1 See B 1-50 Head Light Assembly 1
1a See B 1-50 Replacement Bulb only 1
Not Shown See B 1-50 Wiring Grommet 1
2 See B 1-50 T/D Emblem 1
2a See B 1-50 Emblem Mounting Clips 3
3 See B 1-50 Cowl Moulding 8'
4 See B 1-50 Seat Cushion 2
5 See B 1-50 Seat Backrest 1
Not Shown See B 1-50 Backrest Mounting Screws 6
6 90-443-10 Deck Board (front) 1
6a 90-443-11 Deck Board (rear) 1
6b 90-443-12 Tool box cover plate (steel) 1
7 See B 1-50 Seat Back Moulding 7
8 See B 1-50 Charger AC Cord 1
8a See B 1-50 Mounting Bracket 1
8b See B 1-50 Mounting Bracket Screws 2
8c See B 1-50 Mounting Brackt Nuts 2
8e See B 1-50 AC Cord Strain Releif 1
8f See B 1-50 Replacement AC Plug only 1
9 97-840-01 Vise 1
9a 88-080-16 5/16NC x 2 Hex Bolt (vise) 3
10 91-340-25 Tool Box 1
11 91-530-00 Chain Hook 2
12 30-552-00 1/4 Coil Chain (by the foot) -
13 02-200-05 Ladder Rack 1
13a 88-140-20 1/2 x 3 NC Hex Bolt (ladder rack) 4
13b 88-148-61 1/2 SAE Flat Washer (ladder rack) 8
13c 88-149-81 1/2 NC Hex Lock Nut (ladder rack) 4
Not Shown See B 1-50 Tai light (includes mounting grommet and pigtail) 1
Not Shown See B 1-50 Tail light mounting grommet 1
Not Shown See B 1-50 Tail light pigtail 1
