Illustrated Parts
PARTS PAGE 43
Fiberglass Cab, Doors, Mirrors
ITEM # PART # DESCRIPTION QTY
1 90-852-30 Front Windshield 1
2 98-310-10 Windshield Gasket (by the foot)
3 74-050-00 Windshield Wiper Motor 1
4 74-051-00 Windshield Wiper Arm 1
5 74-052-00 Windshield Wiper Blade 1
6 91-008-00 Fiberglass Cab, B 1-50 1
6a 91-008-20 Fiberglass Cab, MX 1600 1
7 98-310-10 Rear Window Gasket (by the foot)
8 90-850-10 Rear Window 1
9a 91-814-11 Door Hinge(right) 2
9b 91-814-10 Door Hing (left)
10 94-036-00 Door Moulding 13'
11a 90-924-96 Door Cover (left) 1
11b 90-923-10 Door Frame (left) 1
11c 90-924-97 Door Cover (right) 1
11d 90-923-20 Door Frame (right) 1
12 01-200-73 Front Bumper 1
13 88-102-17 Bolt 1
14 16-206-00 Spacer 1
15 88-108-62 Split Lock Washer 3
16 88-109-80 Nut 3
17 97-315-53 Outer Door Handle 2
18 97-315-51 Door Latch 2
19 97-315-54 Inner Door Handle 2
20 92-202-00 Mirror 2
21 92-201-00 Mirror Mounting Bracket 2
22 - - -
23a 88-025-08 Screw 4
23b 88-029-86 Nut 4
24a 88-065-08 Bolt 4
24b 88-069-81 Nut 4
25 88-102-13 Bolt 2
26a 88-082-09 Bolt 8
26b 88-089-81 Nut 8
Not Shown 01-200-70 Rear Support Angle, B 1-50 1
Not Shown 01-200-89 Rear Support Angle, MX 1600
Not Shown 01-200-72 Front Cover (between cab and cowl) 1
Not Shown 90-186-10 Velcro (on door frame)
