TDK-Lambda G30-170 - Page 126

118
NOTE:
Minimum value is limited to 5% above the actual voltage setting value
[SOURce]:VOLTage:PROTection:LOW:DELay <NRf+>
Function
Sets the time delay between UVP fault event and output disable.
Parameters 0.1 ~ 25.5|MIN|MAX. Resolution: 0.1
Note: Round input parameter to closest 100mSec step.
Unit
S
Query [SOURce]:VOLTage:PROTection:LOW:DELay?
VOLTage:PROTection:LOW:DELay? MAX
VOLTage:PROTection:LOW:DELay? MIN
Return
<NR2>
[SOURce]:VOLTage:PROTection:LOW:STATe <Bool>
Function Enables/Disables the under voltage protection (UVP) mode.
If enabled, the output is disabled when measured output voltage reaches
the UVL level.
UVP bit is set in the Questionable Condition register.
Parameters
0|1, OFF|ON
Query
[SOURce]:VOLTage:PROTection:LOW:STATe?
Return
<Bool> 0|1
NOTE:
UVP function is disabled if voltage setting is below 5% of the rated Power Supply voltage.
[SOURce]:VOLTage:PROTection:LOW:LEVel <NRf+>
Function
Sets the under voltage limit level.
Parameters The range is limited by the UVL programming range and voltage
programmed value.
Unit
V
Query [SOURce]:VOLTage:PROTection:LOW:LEVel?;
VOLTage:PROTection:LOW:LEVel? MIN; :VOLTage:PROTection:LOW:LEVel?
MAX
Return
<NR2> 4-digits format
NOTE:
UVL setting is 5% below the actual voltage setting.
