STATus:OPERation:CONDition?
Query Returns the value of the Operational Condition Group Condition register, which is
a read-only register that holds the real-time operational status of the Power
Supply.
Bit configuration of the Operational Condition Group Condition register is as
follows:
Position
Value
Name
Position
15
32768
CP
7
14
16384
CPE
6
13
8192
ECR
5
12
4096
EVR
4
11
2048
CFB
3
10
1024
ENA
2
9
512
ILC
1
8
256
UVP
0
Value
128
64
32
16
8
4
2
1
Name
LOC
SSA
FBE
AST
TWI
NFLT
CC
CV
CP – Constant Power.
Set to “1” when Power Supply is in
the Constant Power mode.
CPE – Constant Power Enabled.
Set to “1” when Constant Power
Limit mode is ON
ECR – External Current Reference.
Set to “1” when analog current
programming channel is set.
EVR – External Voltage Reference
Set to “1” when analog voltage
programming channel is set.
CFB – Current Foldback enabled.
Set to “1” when Current Foldback is
active. Set to “0” indicates Voltage
Foldback is active.
ENA – Enable Enabled.
Set to “1” if Enable input is active.
ILC – Interlock Enabled.
Set to “1” if Interlock input is
active.
LOC – Local/Remote.
Set to “1” when Power Supply is in the
Local mode.
SSA – Sequencer Step Active.
Set to “1” when sequencer is running.
FBE – Foldback Enabled.
Set to “1” when Foldback system is
active.
AST – Auto Start.
Set to “1 when Auto-Start is enabled
TWI – Trigger Wait.
Set to “1” when Power Supply is
waiting for a trigger.
NFLT – No Fault.
Set to “1” when there are no faults,
according to Questionable Condition
Group Enable register.
CC – Constant Current.
Set to “1” when Power Supply is in the
Constant Current mode.
CV – Constant Voltage.
Set to “1” when Power Supply is in the
Constant Voltage mode.
Returns
<NR1> 0…65535
Example
00136
