14
No.
Control/Indicator
Description
Section
1 Voltage Display 4-digit 16-segment Voltage display.
Normally displays the output voltage.
In preview mode, the display indicates the program setting of
the output voltage.
In menu navigation, the display indicates the selected
function.
2
Operation Mode Indicator
CV/CC/CP operation mode indicator.
3 Current Display 4-digit 16-segment Current display.
Normally displays the output current.
In preview mode, the display indicates the program setting of
the output current.
In menu navigation, the display indicates the selected
parameter.
4 LFP Indicator Locked Front Panel indicator.
LFP is on if the Front Panel is locked.
5 AUTO Indicator AUTO-Start indicator.
AUTO is on if the Auto-Start mode is active.
6 SAFE Indicator SAFE-Start indicator.
SAFE is on, if the Safe-Start mode is active.
7 FOLD VI Indicator Foldback indicator.
FOLD V is on if Foldback CV is active.
FOLD C is on if Foldback CC is active.
8 Power / Address Indicator If power supply output is ON, actual output power is
displayed.
If power supply output is OFF, power supply address is
displayed.
* The address is displayed while Communication menu is
active, regardless of the power supply output state.
9 ext V / ext I Indicators External Voltage / External Current Analog Programming
Indicators.
ext V is on if Analog Voltage Programming channel is active.
ext I is on if Analog Current Programming channel is active.
