15
10 REM Indicator REMOTE indicator.
REM is on if power supply is controlled by a remote
communication (RS232/485, USB, LAN, OPTional).
11 RS Indicator Recommended Standard indicator.
RS232 or RS485 communication type is selected.
12 USB Indicator Universal Serial Bus indicator.
USB communication type is selected.
13 LAN Indicator Local Area Network indicator.
LAN communication type is selected.
14 OPT Indicator Optional communication type indicator.
Optional communication type is selected.
15 TRIG Indicator Trigger Indicator.
TRIG is on if the trigger-in is enabled and initialized.
power supply is ready to receive trigger-in signal.
16 Active Memory-Cell
Indicator
Display active memory cell.
1,2,3,4 – A sequence is loaded from cells 1,2,3 or 4
_ - A sequence is loaded from a PC
The Indicator is blinking if a sequence is running.
Table 2-2: Front Panel Display and Indicators
