Control via the serial communication port
The following parameters can be programmed via the serial communication port:
Output voltage measurement.
Output current measurement.
Foldback protection setting
voltage protection setting and readback.
Voltage limit setting and readback.
supply start up mode (last setting or safe mode).
Analog voltage programming and monitoring
Analog inputs and outputs are provided at the rear panel for analog control of the power supply. The
put voltage and the current limit can be programmed by analog voltage or by resistor, and can be
tored by analog voltage. The power supply output ca
n be remotely set to On or Off and analog
signals monitor the proper operation of the power supply and the mode of operation (CV/CC).
power supplies of the same output voltage and current rating can be paralleled in master
e configuration with automatic current sharing to i
Output connections are made to rear panel via bus
bars up to 300V. For greater than 300V
terminals. Either the positive or negative terminal may be gro
unded or the output may be floated. Co
tance with higher float voltage applications. Local or remote sense may be used. In
remote sense, the voltage drop on the load wires should be minimized. Refer to the specifications for
Cooling and mechanical construction
series is cooled by internal fans. At the installation, care must be taken to allow free
flow into the power supply via the front panel and out of the power supply via the rear pan
Observe all torque guidelines within this manual. Over torqueing may da
unit or accessories. Such damage is not covered under manufacturer’s wa
