CHAPTER 1 GENERAL INFORMATION
1.1 USER
MANUAL CONTENT
This User’s Manual contains the operating instructions, installation instructions and specifications of the
Genesys
TM
15KW and 10KW power supply series. The instructions refer to the standard power su
p-
plies, including the built
-
in RS232/485
serial communication. For information related to o
p
eration with
the optional IEEE programming, refer to User’s Manual for Power Supply IEEE/IEMD Programming
I
n
terface. For information related to operation with the optional LAN programming, refer to the U
ser’s
Manual for Power Supply LAN Programming Interface.
1.2 INTRODUCTION
1.2.1
General Description
Genesys
TM
power supplies are wide output range, high performance switching power supplies. The
Genesys
TM
series is power factor corrected and operates from specif
ied AC voltage range contin
u-
ously. Output voltage and current are continuously displayed and LED indicators show the complete
operating status of the power supply. The Front panel controls allow the user to set the output param
e-
ters, the protections levels
(Over
-
Voltage protection, Under
-
Voltage limit and Foldback) and preview
the se
t
tings. The rear panel includes the necessary connectors to control and monitor the power supply
operation by remote analog signals or by the built
-
in serial communication (RS23
2/485). GPIB pr
o-
gramming and Isolated
-
Analog programming/monitoring are optional
1.2.2
Features and options

Constant Voltage / Constant Current with automatic crossover.

Embedded Microprocessor Controller.

Built
-
in RS
-
232/RS
-
485 Interface.

Voltage & Current high
resolution adjustment by digital encoders.

High accuracy programming/readback.

Last Setting Memory.

Independent Remote ON/OFF (opto
-
isolated) and remote Enable/Disable.

Remote sensing to compensate for voltage drop of power leads.

External Analog Programm
ing and Monitoring standard (0
-
5V or 0
-
10V, user selectable).

Zero stacking
-
no ventilation required at the top and bottom surface of the power supply.

Optional GPIB interface (SCPI compatible).

Optional Isolated Analog programming/monitoring (0
-
5V or 0
-
10V
, user selectable and 4
-
20mA).
