When the Isolated Analog Option is installed, do not apply any signals to the
isolated VPGM and IPGM (J1
10) pins. All other J1 features may
be used normally. Refer to Section 4.5 for a description of J1 features.
To prevent damage to the unit, do not program the output voltage and
current to higher then the power supply rating.
12 must be shorted together with a jumper.
12 must be shorted together with a jumper.
SW1 position 3 and 4 must be in their Up position for operation
20mA Isolated Programming and Monitoring.
8.4 SETUP AND OPERATING INSTRUCTIONS
8.4.1 Setting up the power sup
Perform the following procedure to configure the power supply.
Turn the power supply AC power switch to Off.
Connect a short between J1
Set the Setup switch SW1 positio
ns 1 and 2 to their Up position.
Set SW1 position 3 to select the programming voltage range: Down=0
Set SW1 position 4 to select the monitoring range: Down=0
Ensure that SW1 positions 7 and 8 are in their down position.
the programming sources to the mating plug of the Isolated Programming connector. O
rect polarity of the voltage source.
Set the programming sources to the desired levels and turn the power supply ON.
Setting up the power supply fo
20mA Isolated Programming and Monitoring
Perform the following procedure to configure the power supply:
Turn the power supply AC power switch to Off.
Connect a short between J1
Set the Setup switch SW1 positions 1 and
Set SW1 position 3 to its Up position.
Set SW1 position 4 to its Up position.
Ensure that SW1 positions 1 and 2 to their Up position.
Connect the programming source to the mating plug of the Isolated Programming connector.
rect polarity of the voltage source.
Set the programming sources to the desired levels and turn the power supply ON.
