TDK-Lambda GENESYS 10KW - Command Set Description and Categories

83
-
530
-
000 Rev
G
54
C01
Illegal command or query
C02
Missing parameter
C03
Illegal parameter
C04
Checksum error
C05
Setting out of range
7.7 COMMAND SET DESCRIPTION
7.7.1
General guide
1.
Any command or argument may be in
capital letters or small letters.
2.
In commands with an argument, a space must be between the command and the arg
u
ment.
3.
For any command that sets a numeric value, the value may be up to 12 characters long.
4.
Carriage Return: If the CR character (ASCII 13) is r
eceived by itself, the power supply will
respond with “OK” and CR.
7.7.2
Command set categories
1.
Initialization control
2.
ID control
3.
Output control
4.
Status control
7.7.3
Initialization control commands
#
Command
Description
1
ADR n
ADR is followed by address, whic
h can be 0 to 30 and is used to access the power
supply.
2
CLS
Clear status. Sets FEVE and SEVE registers to zero (refer to Section 7
-
11).
3
RST
Reset command. Brings the power supply to a safe and known state:
Output voltage: zero, Remote: non
-
locko
ut remote,
Output current: zero, Auto
-
start: Off,
Output: Off, OVP: maximum,
FOLD: Off, UVL: zero
The conditional registers (FLT and STAT) are updated, the other registers are not
changed.
4
RMT
Sets the power
supply to local or remote mode:
1.
RMT 0 or RMT LOC, sets the power supply into Local mode.
2.
RMT 1 or RMT REM, sets the unit into remote mode.
3.
RMT 2 or RMT LLO, sets the unit into Local Lockout mode (latched r
e
mote mode).
5
RMT?
Returns to the Remote mode set
ting:
1.
“LOC”
-
The unit is in Local mode.
2.
“REM”
-
The unit is in Remote mode.
3.
“LLO”
-
The unit is in Local Lockout (latched remote) mode.
6
MDAV?
Returns MD MODE OPTION Status. 1 indicates installed and 0 indicates not i
n-
stalled.
7
\
Repeat last command.
If
\
<CR> is received, the power supply will repeat the last
command.
7.7.4
ID control commands
#
Command
Description
