7.11 SERIAL COMMUNICATION TEST SET
-
UP
Use the following instructions as basic set
-
up to test the serial communication operation.
1.Equipment
: PC with Windows Hyper Terminal, software installed, Genesys
TM
Power supply, RS232 cable.
2. PC set
-
up
:
2.1 Open Hyper Terminal…………………….
New Connection.
2.2 Enter a name
2.3 Connect to…………………………………
Direct to Com 1 or Com 2
2.4 Configure port properties:
Bits per second……9600
Data bits……………8
Parity……………….None
Stop bits……………1
Flow control……….None
2.5 Open Properties in the program
File………………….Properties
2.6 Setting:
ASCII Set Up
Select Echo characters locally, select send line ends with line feed.
On some PC systems, pressing the number keypad “E
n
ter” will distort
displayed messages. Use the alphabetic “E
n
ter” instead.
3.Power supply set
-
up:
Connect the power supply to the PC using the RS232 cable.
Set via the front panel: Baud Rate: 9600, Address: 06 (default).
Set via the rear panel: RS232/485 to RS232 (refer to
Section: 4
-
4).
4.
Communication Test:
Model identification:
PC: write: ADR 06
Power supply response: “OK”
Command test:
PC write: OUT1
Power supply response: “OK”
PC write: PVn
Power supply response: “OK”
PC write: PCn (for values of n see Tables 7
-
4, 7
-
5 a
nd 7
-
6)
Power supply response: “OK”
The power supply should turn on and the display will indicate the actual output voltage
and the actual output current.
