1.3 ACCESSORIES
1.3.1 Included Accessories
-
The following accessories are
delivered with the power supply.
1.3.1.1
Serial Link Cable
:
Serial linking cable linking power supplies by RS
-
485 communication.(GEN/RJ45).
Cable description: 0.5m Length, shielded, RJ
-
45 type plugs, eight (8) contacts (P/N 15
-
507
-
201)
1.3.1.2
Hardware
:

Strain Relief for AC Cord

Output terminal Shield

DB25 Programming Plug kit (AMP 749809
-
9)
1.3.2
Optional Communicati
on Cables

RS
-
232 Cables to connect GEN to Serial Port on PC

RS
-
485 Cable to connect GEN to Serial Port on PC
GEN
to PC(DB9)
GEN/485
-
9
P/N 15
-
507
-
202
1.
3.3
AC cables
–
Not applicable.
GEN to PC (DB9)
GEN 232/9
P/N 15
-
507
-
203
GEN to PC (DB25)
GEN 232/25
P/N 15
-
507
-
204
