83
-
530
-
000 Rev
G
16
Input Terminal Block
with cover.
Input Terminal Block
Input Rating
Label
NOTE: The figure shows input
connection from left side.
For connection from right side
reverse the input cover.
Figure 3.1
3.7.1 Reco
m
mended Cable Size for Input Connection
INPUT VOLTAGE
CURRENT RMS AMPS
PER PHASE
RECOMMENDED
COPPER WIRE SIZE
208
75
4 AWG
400
45
6 AWG
480
35
7 AWG
The AC input current and voltage rating is marked on the rear terminal of the power supply.
The Protective Earth Ground
must be co
n
nected
before applying AC Line Power to the power supply.
