83
-
530
-
000 Rev
G
30
Fig. 4
-
3: SW1 setup DIP switch
SW1 position function
Refer to Ta
ble 4
-
3 for description of SW1 position functions. The factory default setting is Down for
all positions. Observe ESD precautions when setting switch positions.
Table 4
-
3: SW1 positions functions
Position
Function
DOWN
(Factory default)
UP
SW1
-
1
Output V
oltage remote
Analog programming
Output Voltage
Programmed by Front
Panel
Output Voltage
programmed by remote
an
a
log voltage
SW1
-
2
Output Current remote
analog programming
Output Current
programmed by Front
Panel
Output Current
programmed by remote
an
a
log voltage
SW1
-
3
Programming range select
(Remote voltage/resistive)
0
-
5V (0
-
5Kohm)
0
-
10V (0
-
10Kohm)
SW1
-
4
Output Voltage and
Current Monitoring Range
0
-
5V
0
-
10V
SW1
-
5
Shut
-
Off Logic select
Off: Low (0
-
0.6V) or Shor
t
On: High (2
-
15V) or Open
Off: Low (2
-
15V) or Open
On: High (0
-
0.6V) or Short
SW1
-
6
RS232/485 select
RS232 interface
RS485 interface
SW1
-
7
Output Voltage resistive
programming
Output Voltage
programmed by Front
Panel
Output Voltage
programmed by external
r
e
sistor
SW1
-
8
Output Current resistive
programming
Output Current
programmed by Front
Panel
Output Current
programmed by external
r
e
sistor
SW1
-
9
Enable/Disable control
Rear panel
Enable
/Disable control is
not active
Rear panel
Enable/Disable control is
a
c
tive
Resetting the SW1 switch
Before making any changes to the SW1 switch setting, disable the power supply output by pres
s
ing
the front panel OUT button. Ensure that
the output voltage falls to zero and OUT LED is off. Then
use any small flat
-
bladed screwdriver to change the SW1 switch setting.
