5.14.1 Series connection for increased output voltage
In this mode, two units are connected so tha
t their outputs are summed. Set the current limit of each
power supply to the maximum that the load can handle without damage. It is recommended that d
be connected in parallel with each unit output to prevent reverse voltage during start up s
case one unit shuts down. Each diode should be rated to at least the power supply rated output voltage
and output current. Refer to Fig.5
ries operation with local and remote sensing.
Remote programming in series operation for in
1. Programming by external voltage:
The analog programming circuits of this power supply are
referenced to the negative Sense (
fore, the circuits used to control each series connected
unit must be separated and f
loated from each other using
the Isolated Analog option.
2. Using the SO function and PS_OK signal: The Shut
Off and PS_OK circuits are referenced to the
lated interface common, IF_COM (J1
IF_COM terminals of different units can be connected t
obtain a single control circuit for the power supplies co
nected in series. See Section 5.16 for d
Do not connected power supplies from diffe
manufacturers in series or in p
When power supplies are connected in series, and
oad or one of the output terminals is grounded,
no point may be at a greater potential of +/
from ground for models up to 60VDC Rated Output
600VDC from ground for models >60VDC
Rated Output. When using RS232/485 or IEEE,
