Parameter Factory Default Resetting Last setting Save & Recall
Output Status OFF OFF + +
Voltage Set-point 0V 0V + +
Current Set-point MAX 0A + +
Fold Back mode OFF OFF + +
Over Voltage Protection
OVP
MAX MAX + +
Under Voltage Level/
Protection mode
OFF (UVL) OFF (UVL) + +
Under Voltage Level/
Protection level
0V 0V + +
Auto Start Mode SAFE SAFE + +
Control pin 1 High High + +
Control pin 2 High High + +
Input Trigger Source EXT EXT + -
Protection Delay 0mS 0mS + +
Voltage Programming
Mode
Digital - + -
Current Programming
Mode
Digital - + -
Programming and Monitor
Range
5V - + -
Current Share Mode
{Master|Slave}
(Master H1) - + -
Interlock (PROTote Inhibit) OFF (disabled) OFF (disabled) + -
Shutdown Logic 1 (positive) - + -
Remote mode LOC LOC + +
Communication Mode RS232 - + -
Address 6 - + -
Baud Rate 9600 - + -
Language SCPI - + -
Lock/unlock front panel Unlock - + -
LIST and WAVE subsystems OFF OFF - -
Program Step AUTO - - -
Trigger Out OFF OFF + +
PS_OK delay 0mS 0mS + +
Special Voltage Under limit
SVUL
Rated - + -
Special Current Under limit
SCUL
Rated - + -
Enable registers Clear Clear - -
Event registers Clear Clear - -
Table 5-7: Memory parameters.
