8.5 Trigger
8.5.1 Input Trigger
Trigger source can be set via:
• BUS - Command (Refer to section 7.11 *TRG, 7.12 TRIGger) or Front Panel.
• EXT - Rear panel connector J3-8 (Refer to section 4.3.2).
Input Trigger source setting via Front Panel:
1. Press MENU button. MENU (green) LED illuminates. “et” message appears on the Voltage
display.
2. Rotate Voltage Encoder until "t ri G" message appears.
3. Press Voltage Encoder. “iit” message appears on Current Display.
4. Rotate Voltage Encoder until “TR
. i” message appears. Press Voltage Encoder.
5. “Tr  i” message appears on Voltage Display and “EH t” or “BS” messages appear on Current
Display. Rotate to scroll list and press current Encoder to select.
8.5.2 Output Trigger
Rear panel connector J3-3 (Refer to section 4.3.2). There are three output trigger modes:
Programming Mode NONE, FIX:
• OFF – No Trigger out.
• In TRIG mode, trigger is generated when output status changes.
• In Function Strobe mode, an output pulse is generated automatically any time an output
parameter such as output, voltage or current is programmed.
Programming modes LIST or WAVE:
• OFF – No Trigger out.
• In TRIG mode, trigger is generated when LIST or WAVE is completed.
• In Function Strobe mode, an output pulse is generated automatically any time a step is competed.
Output Trigger mode settings:
1. Press MENU button. MENU (green) LED illuminates. “et” message appears on the Voltage
display.
2. Rotate Voltage Encoder until “t ri G” message appears.
3. Press Voltage Encoder. “iit” message appears on Current Display.
4. Rotate Voltage Encoder until “TR
. ov” message appears. Press Voltage Encoder.
5. “Tr  ov” message appears on Voltage Display and “OFF” , “T Ri G ”, “F . Str” messages appear on
Current Display. Rotate to scroll list and press current Encoder to select.
8.6 Transient Waveform Example
8.6.1 Wave Programing
1. Select required transient operation mode Insert communication command ( Example: VOLT:MODE
WAVE ).
2. Set Voltage values Insert communication command ( Example: WAVE:VOLT 5,10,10,0 ).
3. Set Timing values Insert communication command ( Example: WAVE:TIME 0,2,3,2 ).
4. Set Counter value for sequence execution ( Example: WAVE:COUN 2 ).
5. Set Step parameter AUTO or ONCE ( Example: WAVE:STEP AUTO ).
6. In this step possible store program in memory and continue programming without PC
connection Insert communication command ( Example: WAVE:STORe 2 ).
7. Recycle AC power. Set OUT ON.
