TDK-Lambda Z+ series - Trigger Subsystem

108
7.12.11 TRIGger Subsystem
TRIGger
[:START] Run trigger
DELay <NRf+> Set trigger delay
:SOURce <CRD> Set trigger source
NOTE:
The Trigger subsystem must be enabled from the Initiate subsystem or no triggering action will occur.
TRIGger
When the Trigger subsystem is enabled, TRIG generates an immediate trigger signal that bypasses
selected TRIG:DEL.
SCPI Command Syntax TRIGger[:STARt][:IMMediate]
GEN Command Syntax None
Parameters None
Returned Parameters TRIG TRIG:IMM
Query Syntax None
TRIGgger:DELay
Sets the time delay between the detection of an event on the specified trigger source and the
start of any corresponding trigger action on the power supply output.
SCPI Command Syntax TRIGger[:STARt]:DELay <NRf+>
GEN Command Syntax None
Default Suffix S
*RST Value 0
Examples TRIG:DEL .25 TRIG:DEL MAX
Query Syntax TRIGger[:STARt]:DELay?
Returned Parameters <NR3> 0…65.000s
TRIGger:SOURce
Selects the power supply input trigger source as follows:
• BUS (*TRG & TRIG) and Front Panel
• EXT Mainframe backplane Trigger IN PIN
SCPI Command Syntax TRIGger[:STARt]:SOURce <CRD>
GEN Command Syntax None
Parameters BUS | EXT
*RST Value EXT
Examples TRIG: SOUR BUS
Query Syntax TRIGger[:STARt]:SOURce?
Returned Parameters BUS | EXT
