TDK-Lambda Z+ series - Page 98

97
NOTE:
VOLT:MODE LIST and WAVE is an implied ABORT command. WAVE mode cannot be programmed
simultaneously for both Voltage and Current. Only the last sent command can be accepted as WAVE.
Previous mode reverts to NONE.
VOLTage:PROTection:LEVel
Sets the OVP level. The OVP setting range is given in Table 7-8. The number of characters after OVP
is up to 12. The minimum setting level is approx. 105% of the set output voltage, or the value in
Table 7-8, whichever is higher.
SCPI Command Syntax [SOURce]:VOLTage:PROTection:LEVel <nn.nn|MAX>
GEN Command Syntax OVP < NRf+>
Default Suffix V
*RST Value MAX
Examples VOLT:PROT:LEV 2.5
Query Syntax
[SOURce]:VOLTage:PROT:LEV?
VOLT:PROT:LEVel? MIN VOLT:PROT:LEVel? MAX
Returned Parameters
<NR3> VOLT:PROT:LEV? returns presently programmed OVP level. VOLT:PROT:LEV?
MAX and VOLT:PROT:LEV? MIN return the maximum and minimum programmable
OVP levels.
NOTE:
VOLT:PROT:LEV MIN set OVP level 5% above voltage set value
VOLTage:PROTection:LOW:STATe
Sets the under voltage protection (UVP) status of the power supply. If the UVP status selected,
then the under voltage protection is enabled.
SCPI Command Syntax [SOURce]:VOLTage:PROTection:LOW:STATe <CRD>
GEN Command Syntax UVL < NRf+> , UVP < NRf+>
Parameters UVL|UVP
*RST Value UVL
Examples VOLT:PROT:LOW:STAT UVP
Query Syntax [SOURce]:VOLTage:PROTection:LOW :STATe?
Returned Parameters UVP|UVL
