TECDrive20-EU Series Inverter Function parameters
-98-
Function
code
Name
Description
Default
Modify
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the
inverter
Range: 0.00Hz–P00.03
●
P17.03
Output voltage
Display current output voltage of the inverter
Range: 0–1200V
●
P17.04
Output current
Display current output current of the inverter
Range: 0.0–5000.0A
●
P17.05
Motor speed
Display the rotation speed of the motor.
Range: 0–65535RPM
●
P17.06
Torque current
Display current torque current of the inverter
Range: 0.0–5000.0A
●
P17.07
Magnetized
current
Display current magnetized current of the
inverter
Range: 0.0–5000.0A
●
P17.08
Motor power
Display current power of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
●
P17.09
Output torque
Display the current output torque of the inverter.
Range: -250.0–250.0%
●
P17.10
Motor
frequency
evaluation
Evaluate the motor rotor frequency on open loop
vector
Range: 0.00–P00.03
●
P17.11
DC bus voltage
Display current DC bus voltage of the inverter
Range: 0.0–2000.0V
●
P17.12
Switch input
terminals state
Display current Switch input terminals state of
the inverter
Range: 0000–00FF
●
P17.13
Switch output
terminals state
Display current Switch output terminals state of
the inverter
Range: 0000–000F
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
inverter.
Range : 0.00Hz–P00.03
●
P17.15
Torque
reference
Display the torque reference, the percentage to
the current rated torque of the motor.
Setting range: -300.0%–300.0%
(of the rated motor current)
●
