TECDrive20-EU Series Inverter Function parameters
-99-
Function
code
Name
Description
Default
Modify
P17.16
Linear speed
Display the current linear speed of the inverter.
Range: 0–65535
●
P17.18
Counting value
Display current counting number of the inverter.
Range: 0–65535
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00–10.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00–10.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00–10.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.000–50.000kHz
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0–100.0%
●
P17.24
PID feedback
value
Display PID feedback value
Range: -100.0–100.0%
●
P17.25
Power factor of
the motor
Display the current power factor of the motor.
Range: -1.00–1.00
●
P17.26
Current
running time
Display the current running time of the inverter.
Range: 0–65535min
●
P17.27
Simple PLC
and present
stage of
multi-step
speed
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
●
P17.28
ASR controller
output
The percentage of the rated torque of the relative
motor, display ASR controller output
Range: -300.0%–300.0% (rated motor current)
●
P17.32
Magnetic flux
linkage
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
●
P17.33
Exciting current
reference
Display the exciting current reference in the
vector control mode.
Range: -3000.0–3000.0A
●
P17.34
Torque current
reference
Display the torque current reference in the vector
control mode.
Range: -3000.0–3000.0A
●
P17.35
AC input
current
Display the input current in AC side.
Range: 0.0–5000.0A
●
