TECDrive20-EU Series Inverter Dimension drawings
-148-
Model
W1
W2
W3
H1
H2
D1
D2
Mounting
hole
diameter (d)
Weight
(kg)
TDI20-1R5G-2-EU
146.0
131.0
—
256.0
243.5
167.0
84.5
Ø 6
3.1
TDI20-2R2G-2-EU
146.0
131.0
—
256.0
243.5
167.0
84.5
Ø 6
3.1
TDI20-004G-2-EU
146.0
131.0
—
256.0
243.5
167.0
84.5
Ø 6
3.1
TDI20-5R5G-2-EU
170.0
151.0
—
320.0
303.5
196.3
113.0
Ø 6
5.58
TDI20-7R5G-2-EU
170.0
151.0
—
320.0
303.5
196.3
113.0
Ø 6
5.83
TDI20-004G-4-EU
146.0
131.0
—
256.0
243.5
167.0
84.5
Ø 6
3.1
TDI20-5R5G-4-EU
146.0
131.0
—
256.0
243.5
167.0
84.5
Ø 6
3.1
TDI20-7R5G-4-EU
170.0
151.0
—
320.0
303.5
196.3
113.0
Ø 6
5.58
TDI20-011G-4-EU
170.0
151.0
—
320.0
303.5
196.3
113.0
Ø 6
5.58
TDI20-015G-4-EU
170.0
151.0
—
320.0
303.5
196.3
113.0
Ø 6
5.83
TDI20-018G-4-EU
200.0
185.0
—
340.6
328.6
184.3
104.5
Ø 6
9
TDI20-022G-4-EU
200.0
185.0
—
340.6
328.6
184.3
104.5
Ø 6
9
TDI20-030G-4-EU
250.0
230.0
—
400.0
380.0
202.0
123.5
Ø 6
15.5
TDI20-037G-4-EU
250.0
230.0
—
400.0
380.0
202.0
123.5
Ø 6
15.5
TDI20-045G-4-EU
282.0
160.0
226.0
560.0
542.0
238.0
138.0
Ø 9
25
TDI20-055G-4-EU
282.0
160.0
226.0
560.0
542.0
238.0
138.0
Ø 9
25
TDI20-075G-4-EU
282.0
160.0
226.0
560.0
542.0
238.0
138.0
Ø 9
25
TDI20-090G-4-EU
338.0
200.0
—
554.0
535.0
329.2
—
Ø 9.5
45
TDI20-110G-4-EU
338.0
200.0
—
554.0
535.0
329.2
—
Ø 9.5
45
Installation hole
Figure B-9 Flange mounting of 3PH 400V 4–75kW and 3PH 230V 1.5–7.5kW inverters
