TECDrive20-EU Series Inverter Function parameters
-55-
Function
code
Name
Description
Default
Modify
gain
during compensation SVPWM control to improve
the rigidity of the motor. It can be set to the rated
slip frequency of the motor which is counted as
below:
△f=f
b
-n*p/60
Of which, f
b
is the rated frequency of the motor,
its function code is P02.02; n is the rated rotating
speed of the motor and its function code is
P02.03; p is the pole pair of the motor. 100.0%
corresponds to the rated slip frequency△f.
Setting range: 0.0–200.0%
P04.10
Low frequency
vibration
control factor
In the SVPWM control mode, current fluctuation
may occur to the motor on some frequency,
especially the motor with big power. The motor
cannot run stably or overcurrent may occur.
These phenomena can be canceled by adjusting
this parameter.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (the
max. frequency)
10
○
P04.11
High frequency
vibration
control factor
10
○
P04.12
Vibration
control
threshold
30.00
Hz
○
P04.26
Energy-saving
operation
selection
0: No operation
1: Automatic energy-saving operation
Motor on the light load conditions, automatically
adjusts the output voltage to save energy
0
◎
P04.27
Voltage Setting
channel
Select the output setting channel at V/F curve
separation.
0: Set via keypad: the output voltage is
determined by P04.28.
1: Set via AI1
2: Set via AI2
3: Set via AI3
4: Set via HDI
5: Set via multi-step (the set value is determined
by the multi-step speed in P10 group)
6: Set via PID
7: Set via Modbus communication
8–10: Reserved
0
○
