TECDrive20-EU Series Inverter Function parameters
-70-
Function
code
Name
Description
Default
Modify
of running state
BIT1: Analog AI2 value (V on)
BIT2: Analog AI3 value (V on)
BIT3: High speed pulse HDI frequency
BIT4: Motor overload percentage (% on)
BIT5: The inverter overload percentage (% on)
BIT6: Ramp frequency reference (Hz on)
BIT7: Linear speed
BIT8: AC inlet current (A on)
BIT9–15: Reserved
P07.07
The parameter
selection of the
stop state
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency flickering
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminals state
BIT3: Output terminals state
BIT4: PID reference (% flickering)
BIT5: PID feedback value (% on)
BIT6: Torque reference (% flickering)
BIT7: AI1 (V on)
BIT8: AI2 (V on)
BIT9: AI3 (V on)
BIT10: High-speed pulse HDI frequency
BIT11: PLC and the current step of multi-step
speed
BIT12: Pulse counters
BIT13–BIT15: Reserved
0x00FF
○
P07.08
Frequency
display
coefficient
0.01–10.00
Displayed frequency=running frequency* P07.08
1.00
○
P07.09
Speed display
coefficient
0.1–999.9%
Mechanical rotation speed =60 x (Displayed
running frequency) × P07.09/(Number of motor
pole pairs)
100.0%
○
P07.10
Linear speed
displayed
coefficient
0.1–999.9%
Linear speed= Mechanical rotation
speed×P07.10
1.0%
○
P07.11
Rectifier bridge
-20.0–120.0°C
●
