TECDrive20-EU Series Inverter Function parameters
-72-
Function
code
Name
Description
Default
Modify
P07.30
Type of the last
but two fault
6: Overcurrent during constant speed running
(OC3)
7: Overvoltage during acceleration (OV1)
8: Overvoltage during deceleration (OV2)
9: Overvoltage during constant speed running
(OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: inverter overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Braking unit fault (bCE)
24: Running time reached (END)
25: Electronic overload (OL3)
26: Keypad communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
29–31: Reserved
32: To-ground short-circuit fault 1 (ETH1)
33: To-ground short-circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Mal-adjustment (STo)
36: Underload fault (LL)
37: Safe torque off (STO)
38: Channel H1 abnormal (STL1)
39: Channel H2 abnormal (STL2)
40: Internal circuit abnormal (STL3)
41: Safety code FLASH CRC check fault (CrCE)
●
P07.31
Type of the last
but three fault
●
P07.32
Type of the last
but four fault
●
P07.33
Reference frequency of present fault
0.00Hz
●
P07.34
Ramps reference frequency of present fault
0.00Hz
●
P07.35
Output voltage of present fault
0V
●
P07.36
Output current of present fault
0.0A
●
P07.37
Bus voltage of present fault
0.0V
●
P07.38
Max. temperature of present fault
0.0°C
●
