Ones place:
0: Keep on integral adjustment when the
frequency achieves the upper/lower limit; the
integration shows the change between the
reference and the feedback unless it reaches the
internal integral limit. When the trend between
the reference and the feedback changes, it
needs more time to offset the impact of
continuous working and the integration will
change with the trend.
1: Stop integral adjustment when the frequency
reaches the upper/lower limit. If the integration
keeps stable, and the trend between the
reference and the feedback changes, the
integration will change with the trend quickly.
Tens place:
0: The same with the main reference direction; if
the output of PID adjustment is different from the
current running direction, the internal will output
0 forcedly.
1: Opposite to the main reference direction
Hundreds place:
0: Limit as per the maximum frequency
1: Limit as per A frequency
Thousands place:
0: A+B frequency, main reference A frequency
source buffering ACC/DEC is invalid;
1: Main reference A frequency source buffering
ACC/DEC is valid and the ACC/DEC is
determined by P08.04.
