6. LSServer, Scanner Shell and Download
6-60 Operating Manual for the LS Series Scanner No. 30001798 Rev. No. 1.5 2004-11
Files
AutoSave
check box
Select the AutoSave check box to save every scanned image automatically:
AutoSave on: all files will be stored in designated folder,
AutoSave off: all files will be stored in temp folder,
(see chapter Folder Options)
Filename = title of the image window = standard or special name according to
the selected options in the
Slide Settings tab
Directory =
Tecan Array Pro Software subdirectory = Array Pro 45 \ Images
\...
The images are saved as 16bit TIF format.
Scanning of microplates or other slide adapter formats will open a lot of image
windows in the
Tecan Array Pro Software.
AutoSave is automatically enabled in Stacker Mode; no user action
necessary.
Note
To save memory and user time the first window will be closed after 10 scans.
(10 active pictures is the default setting). So the user won’t see all the scans
at once, just the last 10.
Generate
JPEG
backup
check box
The image will also be saved as a .jpg file and saved in the same folder as the
.tif file.
Note
There must be an equal number of pictures in each column and in each
row, (i.e. the pictures must form a complete rectangle,
e.g. 2 x 3, 4 x 6, etc.)
Improper selection of images to be stitched can cause an unexpected
stitched image result.
