Technicolor TD5130 User Manual

Advanced
6.4 IPv6 WAN
This page allows you to configure IPv6 settings.
To access the IPv6 WAN page, click Advanced > IPv6 WAN.
The table lists the existing IPv6 connection settings. To edit an entry, click the
corresponding icon. To delete an entry, click the corresponding button.
To add a new connection, click the Add button. All required information must be
obtained from your Internet Service Provider (ISP).
6.4.1 Static IPv6
On My IPv6 Connection is, select Static IPv6.
Connection Name — Select an Internet connection to use. This is the connection that
you set up in SETUP > Internet Setup page. See “Internet Setup” on page 21.
WAN IPv6 Address Settings
Connection Name — Enter the connection name provided by your ISP or a desired
connection name.
IPv6 Address — Enter the IPv6 IP address provided by your ISP.
Subnet Prefix Length — Enter the subnet prefix length provided by your ISP.
Default Gateway — Enter the gateway provided by your ISP.
Primary DNS Address and Secondary DNS Address — If provided by your ISP, enter the
DNS server address. Otherwise, leave the fields blank.
Wireless ADSL2+ Gateway 48

Technicolor TD5130 Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
ADSL Standards	ANSI T1.413 Issue 2
ADSL2 Standards	ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ Standards	ITU G.992.5 Annex A
Wireless	802.11b/g
Ethernet Ports	4 x 10/100
USB Ports	1 x USB 2.0
VoIP	No
Security	WEP, WPA, WPA2
