Technicolor TD5130 User Manual

Advanced
6.10.2 Statistics
This page displays the filter and rule statistics.
To access the Statistics page, click ADVANCED > Packet Filter > Statistics or click the
Statistics button.
Click the Refresh button to refresh the list.
6.11 Static Route
This page allows you to create routing tables for IPv4 and IPv6 protocols.
To access the Static Route page, click ADVANCED > Static Route.
To create a static route, click the Add button under the desired IP protocol static
route table.
IPv4 Static Route
Rule Enable — Enable or disable rule.
Forwarding Policy Option — Select whether to enable or disable routing.
Rule Name — Enter desired rule name.
Source IP — Enter the source IP address.
Source SubMask — Enter the source subnet mask.
Dest IP — Enter the destination IP address.
Dest SubMask — Enter the destination subnet mask.
Gateway — Enter the gateway.
Interface name — Select the interface to implement the routing.
Click the Apply button to save and activate the static route or click the button to
discard your changes.
Wireless ADSL2+ Gateway 69

Technicolor TD5130 Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
ADSL Standards	ANSI T1.413 Issue 2
ADSL2 Standards	ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ Standards	ITU G.992.5 Annex A
Wireless	802.11b/g
Ethernet Ports	4 x 10/100
USB Ports	1 x USB 2.0
VoIP	No
Security	WEP, WPA, WPA2
