4 Connection of the DVB-receiver
a Connection of the LNBs with the LNB-input (LNB IN) of the DVB-receiver.
b Scart connection of the DVB receiver to the TV set.
c Scart connection of the video cassette device to the VCR-Scart socket of the DVB
receiver.
d Connection of the audio outputs with a HiFi system.
e Power supply connection.
