> Pressing the yellow function key Turn to Sat will turn the antenna towards the
selected satellite position.
9.5 Delete satellite position
In order to delete a satellite position from the satellite list, proceed as follows:
> Select the Current satellite list field with the arrow keys.
> Press the OK key to open the Current satellite list.
> Select the satellite, that you would like to delete with the arrow keys up/down.
> Confirm with OK.
> Select the Delete satellite field with the arrow keys.
> To delete the satellite, press OK and confirm the following messages with OK.
9.6 Reference position
When installing the external system, the motor must be in the reference position (0°). You
can therefore rotate the motor at any time to the this position (0°) with the “Go to refe-
rence position” function.
> Pressing the green function key Ref.position will turn the antenna into the refe-
rence position automatically.
10 Technical data
DBS tuner:
Input frequency range 950.... 2150 MHz
Input level range -65 dBm... -25 dBm
DBS Tuner input (nominal)
Input impedance 75 Ohm
AFC-catchment area +/- 3 MHz
Demodulation Shaped QPSK
Symbol rate 1... 45 Mbaud/s, SCPC/ MCPC
FEC Viterbi and Reed-Solomon
Viterbirates 1/2, 2/3, 3/4, 5/6, 7/8,
automatic adjustment
Roll-off factor 35 %
Display
Type LCD-Matrix-Display (128x64)
Card reader:
Type 2 slot card reader for integrated Conax / Cryptoworks decoding
system
Card reader:
Type 1 Common Interface slot for CA-modules
Power consumption max. 0,3A/5V
Demultiplexing: according to ISO 13818-1
Video decoding:
Video compression MPEG-2 and MPEG-1 compatible
52
