Technogym KINESIS ONE - Cables Passage

KINESIS ONE: Service & Maintenance Manual rev. 2.1
Page 3.1
3. CABLES PASSAGE
KINESIS ONE
Rif. Cable code Length (mm)
A 0R000106AA
2300
B
0R000182AB (CRIMPED) 14300
The two modules of the machine and then the routing of the cables are perfectly
symmetrical, on the two sides.
