KINESIS ONE: Service & Maintenance Manual rev. 2.1
Page 6.21
Figure 6.8-4
5. Remove the 2 seeger (f) and (g).
Figure 6.8-5
6. Use a T wrench and a rubber hammer, to
slightly hit the pulleys support (h) and
remove it from the opposite side, as shown in
figure.
Figure 6.8-6
7. Remove the pulleys support (g), as shown in
figure.
To reassemble the rotating pulley system, follow
the disassembly instructions in reverse order.
