KINESIS ONE: Service & Maintenance Manual rev. 2.1
Page 6.23
Figure 6.9-3
On each bar:
3. Remove the tube spacer (b) from the top of
the bar, as shown in figure to side.
4. Back off the 2 grub screws (c) of the stops
(d), using a 4mm hexagonal wrench, and
remove the stops.
5. Remove the protection sponge (e).
6. Remove the weight stack plates, pulling them
out from the top.
To reassemble the weight stack, follow the
disassembly instructions in reverse order.
