Technogym MA05 - PA07 - Horizontal Bench; Ambient Specifications; Conformity to Regulations

ELEMENT LINE: Service & Maintenance Manual - rev. 1.2
Page 2.16
2.3.25. PA07 – HORIZONTAL BENCH
PA07 – Horizontal bench
stand by max during exercise
172.5 x 160.6 x 130.2 cm
Dimensions
68 x 63 x 39 in
Overall weight 59 Kg – 118 lbs
Be aware:
• The weights in the above tables refer to machines with standard weight stack.
• The dimensions are “length x width x height” related to the user in exercise position.
• The stand by dimensions are the minimum machine dimensions without any
disassembling.
2.4. AMBIENT SPECIFICATIONS
Operating from 5° to 35° C
Temperature
Storage from -20 to 55° C
Operating from 30% to 80% non-condensing
Humidity
Storage from 5% to 85% non-condensing
2.5. CONFORMITY TO REGULATIONS
The machine conforms to the following directives:
Directive Europe USA
Machinery directive
98/37/CEE
Mechanical safety
EN 957-1
EN 957-2
EN 957-4
EN 957-1
EN 957-2
EN 957-4
