ELEMENT LINE: Service & Maintenance Manual - rev. 1.2
Page 6.3
6.3. THE MACHINE IS NOT FLAT
To level the machine, you may adjust the height of the levelling foot as illustrated below:
Figure 6.3-1
1. Lift the machine on one side until you can
access the underside of the foot.
2. Loosen the foot cover piece (B).
3. Tighten or loosen the foot (A) until the
equipment is stable on the floor.
We recommend that 2 people carry out this operation.
