ELEMENT LINE: Service & Maintenance Manual - rev. 1.2
Page 3.1
3. INSTALLING AND MOVING THE
MACHINES
3.1. SPECIFICATIONS AND REQUIREMENTS
For proper installation of the equipment, make sure that:
1. The equipment is installed on a level, vibration-free surface with a sufficient capacity to support
its weight plus that of the user.
2. The area is not dusty or sandy.
3. You have observed the temperature and humidity operating requirements indicated in
paragraph 2.4. “Ambient specifications”.
3.2. INSTALLING AND MOVING THE MACHINES
The equipment is supplied on a pallet, to which it is secured by means of straps. To remove the
equipment from the packing:
1. Cut the carton along the bottom and pull it away from the top;
2. Remove the cellophane by pulling it away from the top;
3. Untie the straps securing the equipment to the pallet;
4. Lift the equipment from the weight stack side and place it on the ground;
5. Remove the spacer from between the two panels of the weight stack.
Do not throw the spacer (A) away as it must be used (putting it in the same position) in
case of any further moving of the machine.
