4.2. WHAT TO ORDER TO AUGMENT THE WEIGHT STACK
Weight stack
Cod. Machine
Standar
d
Powere
d
Parts to power the
weight stack
Assembly
code
MA65 – Abdominal
Crunch
MA10 – Abductor
MA05 – Adductor
MA55 – Arm Curl
MA15 – Shoulder Press
60 kg
120 lbs
80 kg
160 lbs
0F137AA-GG x 4 (weight)
0B178AA
(2)
x 8 (bushing)
0E000018-(KG/LB) x 1 (sticker)
0P000653AA X 1 (selector rod)
R0003980AA-KG
R0003980AA-LB
MA60 – Arm Extension
MA45 – Lower Back
70 kg
140 lbs
90 kg
180 lbs
0F137AA-GG x 4 (weight)
0B178AA
(2)
x 8 (bushing)
0E000018-(KG/LB) x 1 (sticker)
0P000697AA x 1 (selector rod)
R0003981AA-KG
R0003981AA-LB
MA35 – Leg Curl
MA30 – Leg Extension
80 kg
160 lbs
100 kg
200 lbs
0F137AA-GG x 4 (weight)
0B178AA
(2)
x 8 (bushing)
0E000018-(KG/LB) x 1 (sticker)
0P000697AA x 1 (selector rod)
R0003981AA-KG
R0003981AA-LB
MA20 – Chest Press
MA40 – Lat Machine
MA95 – Low Row
MA70 – Pectoral Machines
90 kg
180 lbs
120 kg
240 lbs
0F137AA-GG x 6 (weight)
0B178AA
(2)
x 12 (bushing)
0E000018-(KG/LB) x 1 (sticker)
0P000732AA x 1 (selector rod)
R0003982AA-KG
R0003982AA-LB
MA85 – Crossover cable
(1)
MA80 – Ercolina
MA90 – Ercolina Rehab
25 kg
50 lbs
50 kg
100 lbs
0F137AA-GG x 10 (weight)
0B178AA
(2)
x 20 (bushing)
0E000145-(KG/LB) x 1 (sticker)
0P000745AA x 1 (selector rod)
R0003983AA-KG
R0003983AA-LB
MA25 – Vertical Traction
90 kg
18 lbs
110 kg
220 lbs
0F137AA-GG x 4 (weight)
0B178AA
(2)
x 8 (bushing)
0E000018-(KG/LB) x 1 (sticker)
0P000732AA x 1 (selector rod)
R0003984AA-KG
R0003984AA-LB
CAUTION:
(1)
For the Cable Cross, the elements specified in the upgrade table must be included for each of
the two Ercolina modules which make up the machine.
(2)
Bushings of different thickness are available for more precise adjustment of the weight stack
plates, so that they can all be easily selected using the pin.
CODE THICKNESS (mm)
0B178AA 2.5
0B000563AA 2
0B000562AA 1.5
