ELEMENT LINE: Service & Maintenance Manual - rev. 1.2
Page 3.2
3.3. LIFTING AND MOVING
In case of raising or moving the machine, do not press against casings or other
breakable parts, but only against the frame.
To move the machine, preferably use a tipping trolley, lifting it from the weight stack end using the
wooden insert fitted on the machine for transport
Figure 3.3-1
• If you use different means of transportation as pallet changer or lift truck, adequately protect
the parts of the frame that will be in contact with it.
• Insert the means of transportation (pallet changer or lift truck from the weight stack side.
• Move the machine carefully, making sure it does not overbalance.
Once the machine is in the desired place of installation, level it by adjusting the height of
one or more of the machine feet as described in paragraph 6.3. “The machine is not
flat”.
