ELEMENT LINE: Service & Maintenance Manual - rev. 1.2
Page 5.9
Figure 5.6-4
9. Remove the complete release button i and the
spring (l), sliding them upward.
Figure 5.6-5
10. Remove the spiral pin (m) and separate the
metal part of the release button from the
plastic one (n).
To reassemble the release button, carry out the
above steps in reverse order.
