SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 2.6
SF-6: Low voltage power supply cable
Power supply – Power isolating board
Power isolating
board
J2
Signal Color Power supply
CN2
Terminal
block
CN39
5 + 12 Vdc Red 1 -
6 + 5 Vdc Orange 3 -
7 Black -
-
ground
Yellow-green
5
PE
8 ground Brown 4 -
SF-7: Inverter cable
Driver board – Inverter
Driver board
J5
Signal Color Inverter CN43
- Thermal cutout Green 3 2
1 White -
-
Thermal cutout Gnd
White P24
1
2 Start Grey 1 -
3 Alarm Red AL0 -
4 Alarm Gnd Purple AL1 -
5 Speed Brown O -
6 Speed Gnd Black L -
SF-8: Tread-belt motor cable
Inverter – Tread-belt motor
Inverter Signal Color Motor CN43
U Phase U Black 1 already connected -
V Phase V Black 2 already connected -
W Phase W Black 3 already connected -
- Thermal cutout Black 4 already connected 1
- Thermal cutout Gnd Black 5 already connected 2
PE Earth Yellow-green already connected -
FR-9: Up-down motor cable
Portable connector – Up-down motor cable
Portable
CN25
Signal Color Up-down motor
1 Motor + White already connected
2 Motor - Blue already connected
5 Up-down motor pulses Red already connected
6 Pulse Gnd Black already connected
