SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 2.7
FR-10: Braking resistor cable
Inverter – Braking resistor
Inverter Signal Color Resistor
1 Positive White already connected
RB Negative White already connected
SF-12: CPU cable – lower section
Portable connector – Driver board
Color Driver board Portable
CN29
Signal
J4 J6
1 Up-down motor “down” Green - 3
2 Up-down motor “up” Yellow - 5
3 Up-down motor alarm Blue - 7
4 Up-down motor pulses Purple - 9
5 Pulse Gnd Black-green - 11
6 +12 Vdc Red 1 -
7 Gnd Black 2 -
8 +5 Vdc Red - 2
9 Tread-belt motor speed PWM Grey - 4
10 Start tread-belt motor Brown - 6
11 Tread-belt motor alarm Orange-
yellow
- 8
12 Gnd Black - 12
13 Gnd Grey 3 -
14 +5 Vdc Orange 4 -
FR-13: LED board supply cable
CPU board – LED board
CPU board
K2
Signal Color LED board
K2
1 +5 Vdc Red 1
2 Gnd Black 2
