FR-14: LED board signal cable
CPU board – LED board
CPU board
K12
Signal Color LED board
K12
1 - 1
2 STROLED 2
3 MUX2 3
4 MUX1 4
5 MUX0 5
6 OELED 6
7 SCK 7
8 MOSI 8
9 DOE 9
10 - 10
This cable incorporates a 65 Ohm, 100 MHz coil-less ferrite.
SF-15A: Actuator up-down motor cable
Driver board – Power isolating board
Driver board
J1
Signal Color Power isolating
board
J5
1 Motor + White 1
2 Motor - Blue 2
5 Up-down motor pulses Red 5
6 Pulse Gnd Black 6
SF-15B: Actuator up-down motor cable
Power isolating board – Portable connector
Power isolating
board
J6
Signal Color Portable
CN46
1 Motor + White 1
2 Motor - Blue 2
5 Up-down motor pulses Red 5
6 Pulse Gnd Black 6
RL-17: Emergency cable
CPU board – Emergency button
CPU board
EM
Signal Color Emergency
button
1 Gnd White Already connected
2 Signal Black Already connected
