Removal and Installation Procedures
CH2 OUT10G Board
You need a screw
driver with a T-15 Torx tip and pliers (items 1, 2, and 8).
Removal. To remove the CH 2 OUT10G board, follow these steps: (See
Figure4-19onpage4-40.)
1. Remove the handle unit, snaps, cosmetic covers, front-trim unit, EMI covers,
relay unit (for Option 02 or 06), and AWG12G board.
2. Orient the instrument so that the top is on the work surface.
3. Remove the ļ¬ve screws securing the shield bracket to the chassis.
4. Lift the br
acket away from the chassis.
5. Disconnect the ribbon cable at J500 from the CH2 OUT10G board.
6. Disconnect these cables:
NOTE. For Option 02 or 06, there are no cable connections at J600 and J700
on the C
H2 OUT10G board.
The cable at J600 from the CH2 OUT10G board to the AWG12G board
(J100B).
The cable at J700 from the CH2 OUT10G board to the AWG12G board
(J101B).
The cable at J100 from the CH2 OUT10G board to the AWG12G board
(J110B).
The cable at J110 from the CH2 OUT10G board to the AWG12G board
(J111B).
The cable at J150 from the CH2 OUT10G board to the AWG12G board
(J115B).
The cable at J170 from the CH2 OUT10G board to the AWG12G board
(J116B).
The cable at J690 from the CH2 OUT10G board to the Channel 2 Analog
connector.
The cable at J790 from the CH2 OUT10G board to the Channel 2 Analog
connector.
4ā50 AWG7000B and AWG7000C Series Service Manual
