Performance Verification 1-11
Output voltage accuracy
Follow the steps below to verify that Model 2410 output voltage accuracy is within specified
limits. This test involves setting the output voltage to each full-range value and measuring the
voltages with a precision digital multimeter.
1. With the power off, connect the digital multimeter to the Model 2410 INPUT/
OUTPUT
jac
ks as shown in Figure 1-1.
2. Select the multimeter DC volts measuring function.
3. Set the voltage source protection to >1100V. To do so, press CONFIG and then
SOURCE V-SOURCE menu
to access the CONFIGURE V-SOURCE menu. Then
select PROTECTION, and set the voltage source protection limit to >1100V.
4. Press the Model 2410 SOURCE V key to source voltage, and make sure the source out-
put is turned on
.
5. Verif
y output voltage accuracy for each of the voltages listed in Table 1-2. For each test
poin
t:
• Select the correct source range.
• Set the Model 2410 output voltage to the indicated value.
• Verify that the multimeter reading is within the limits given in the table.
6. Repeat the procedure for negative output voltages with the same magnitude as thos
e
listed
in
Table 1-2.
7. Repeat the entire procedure using the rear panel INPUT/OUTPUT jacks. Be sure to
select th
e rear p
anel jacks with the front panel TERMINALS key.
Table 1-2
Output voltage accuracy limits
Model 2410
source range
Model 2410
output voltage setting
Output voltage limits
(1 year, 18°C–28°C)
200mV
2V
20V
1000V
200.000mV
2.00000V
20.0000V
975.00V
199.360 to 200.640mV
1.99900 to 2.00100V
19.9936 to 20.0064V
974.705 to 975.295V
2410-902-01.book Page 11 Monday, November 7, 2005 2:49 PM
