1-14 Performance Verification
Output current accuracy
Follow the steps below to verify that Model 2410 output current accuracy is within specified
limits. The test involves setting the output current to each full-range value and measuring the
currents with a precision digital multimeter.
1. With the power off, connect the digital multimeter to the Model 2410 INPUT/OUTPUT
jac
ks as shown in Figure 1-2.
2. Select the multimeter DC current measuring function.
3. Press the Model 2410 SOURCE I key to source current, and make sure the source output
is tu
rned
on.
4. Verify output current accuracy for each of the currents listed in Table 1-4. For each
test
poin
t:
• Select the correct source range.
• Set the Model 2410 output current to the correct value.
• Verify that the multimeter reading is within the limits given in the table.
5. Repeat the procedure for negative output currents with the same magnitudes as those
listed in
Table 1-4.
6. Repeat the entire procedure using the rear panel INPUT/OUTPUT jacks. Be sure to
select th
e rear p
anel jacks with the front panel TERMINALS key.
Table 1-4
Output current accuracy limits
Model 2410
source range
Model 2410 output
curre
nt se
tting
Output current limits
(1 year, 18°C–28°C)
1µA
10µA
100µA
1mA
20mA
100mA
1A
1.00000µA
10.0000µA
100.000µA
1.00000mA
20.0000mA
100.000mA
1.00000A
0.99905 to 1.00095µA
9.9947 to 10.0053µA
99.949 to 100.051µA
0.99946 to 1.00054mA
19.9870 to 20.0130mA
99.914 to 100.086mA
0.99640 to 1.00360A
2410-902-01.book Page 14 Monday, November 7, 2005 2:49 PM
