Table 6-1
Analog board parts list
Circuit designation Description Keithley part no.
C200-203, 205-210, 225,
226
, 231, 232, 237, 238
CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C204, 404, 608 ,609, CAP, .01UF, 10%, 50V CERAMIC C-491-.01
550-553
C211-214 CAP, 1000PF,10%, 50V, MONO CERAMIC C-452-1000P
C215-222, 611 CAP,100PF, 5%, 100V, CERAMIC C-465-100P
C223, 224, 227-230, CAP, 33PF, 5%, 100V, CERAMIC C-465-33P
233-236, 239, 240, 320
C241 CAP,1000PF,1%,50V,CERAMIC C-347-1000P
C242, 243,248, 249, CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
252-255, 258-261, 269-271
C244, 245 CAP, .01UF, 10%, 200V CERAMIC C-472-.01
C247 CAP, .01, 5%, 50V, NPO C-514-.01
C250, 290, 291, 297-300, CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
252-255, 258-261, 269-271
C256, 257, 340, 341 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C267, 513 CAPACITOR, SMT C-543-560P
C273-282, 284-289, CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
305-310, 321, 322, 600-602
C283, 337 CAP, 100P, 10%, 100V CERAMIC C-451-100P
C296 CAP,33PF,10%,1000V,CERAMIC C-64-33P
C301, 302 CAP, 1000PF,10%, 50V, MONO CERAMIC C-452-1000P
C311 CAP, 100UF, 20%, 10V, ALUM ELEC C-483-100
C312-319 CAP,10PF,5%,100V,CERAMIC C-372-10P
C323-326, 603, 604, 615 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C329 CAP, 220PF, 10%, 100V, CERAMIC C-451-220P
C331-334 CAP,100PF, 5%, 100V, CERAMIC C-465-100P
C336 CAP,1000PF,10%,1000V,CERAMIC C-64-1000P
C342 CAP, 4.7PF, 5%, 50V, MONO-CERAMIC C-452-4.7P
C400 CAP,270PF,2.5%,630V,POLYPROPYLENE C-405-270P
C401 CAPACITOR SMT C-544-270P
C405, 406 CAP, .15UF,20%,50V, CERAMIC C-418-.15
C407 CAP, 1UF, 20%, 35V, TANTALUM C-494-1
C500, 501 CAPACITOR C-548-.033
C502, 503 CAPACITOR C-549-.047
C504, 505, 534, 535 CAP, 47UF, 20%, 100V ALUM ELEC C-521-47
C512, 514 CAP, 22PF, 10%, 100V, CERAMIC C-451-22P
C515, 541 CAP,.1UF, 20%,50V,CERAMIC C-418-.1
C522, 523, 526, 544, CAPACITOR SMT C-542-1000P
527-529, 547, 532, 533
C539, 540 CAP, 1UF, 20%, 50V CERAMIC C-519-1
C545, 546 CAP, .022U, 10%, 2000V C-550-.022
C549, 272 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
6-4 Replaceable Parts
