R207 RES, 90.9K, 1%, 125mW, METAL FILM R-391-90.9K
R210 RES, 768, 1%, 100MW, THICK FILM R-418-768
R213 RES NET 5K, .1%, 668A TF-243-5K
R216, 318, 274-279, 319, RES, 20K, 1%, 100MW THICK FILM R-418-20K
345, 445
R217 RES, 121K, 1%,100MW, THICK FILM R-418-121K
R218 RES, 80.6K, 1%, 100MW THICK FILM R-418-80.6K
R219, 220, 230, 231, 616, RES, 49.9K, 1%, 100MW THICK FILM R-418-49.9K
482, 221, 483, 373, 374
R222 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R224, 234-237, 244-247, RES, 10K, 1%, 100MW, THICK FILM R-418-10K
281, 282, 284-286, 225
R226, 288, 301, 617, 622,
6
54
, 655, 211, 223, 372
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R227 RES, 6.04K, 1%, 100MW THICK FILM R-418-6.04K
R228, 229 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R240, 243, 248, 251, 253, RES, 4.99K, 1%, 100MW THICK FILM R-418-4.99K
R241, 242, 249, 250, 653,
664
RES
, 140K, 1%, 100MW THICK FILM R-418-140K
R257, 258, 261, 262,265,
266
, 313, 314-317, 366
RES, 4.99K, 1%, 100MW THICK FILM R-418-4.99K
R268-271, 209 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R272, 273 RES, 249K, 1%, 100MW, THICK FILM R-418-249K
R280, 439, 440 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R283, 287, 297, 299, 350, RES, 30.1K, 1%, 100MW, THICK FILM R-418-30.1K
R289, 291 RES, 45.3K, 1%, 100MW THICK FILM R-418-45.3K
R293 RES,243K, 1%, 125MW, METAL FILM R-391-243K
R298, 300 RES, 150K, 1%, 100MW, THICK FILM R-418-150K
R302 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R303 RES, 3.01K, 1%, 100MW THICK FILM R-418-3.01K
R304-306 RES, 33, 5%, 250mW, METAL FILM R-376-33
R311, 312, 334, 337, 339, RES, 4.99K, 1%, 100MW THICK FILM R-418-4.99K
335
R320 RESISTOR R-461-10M
R332, 604, 606, 423, 429,
4
30
, 505, 510, 551
RES, 499, 1%, 100MW THICK FILM R-418-499
R338, 364, 402-404, 416,
417
, 459, 488, 153, 239
RES, 100K, 1%, 100MW THICK FILM R-418-100K
R340, 343, 361, 362, 365,
369
, 336, 353, 480, 481
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R341, 342 RES, 13K, 1%, 100MW, THICK FILM R-418-13K
R346, 370, 294 RESISTOR R-461-2M
R347 THICK FILM TF-261
Table 6-1 (cont.)
Ana
log board parts list
Circuit designation Description Keithley part no.
Replaceable Parts 6-7
2410-902-01.book Page 7 Monday, November 7, 2005 2:49 PM
