K1 RELAY, SURFACE MOUNT RL-188
L1 FERRITE CHIP 600 OHM BLM32A07 CH-62
LS1 BEEPER, 5V, 30MA, QMX-05 EM-6
P1001 CABLE ASSEMBLY CA-152-1
P1003 CABLE ASSEMBLY CA-32-9B
P1004, 1002 CABLE ASSEMBLY CA-62-4B
Q1-6 TRANS, N-MOSFET, VN0605T TG-243
Q7,8 POWER MOSFET IRFZ346 TG-313
Q10 TRANS, NPN, MMBT3904 TG-238
R1,37 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R2, 13, 4, 52, 14, 19, 34, 35, 50,
5
8
, 63, 68, 62, 75
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R5 RES, 10M, 1%, 125MW, THICK FILM R-418-10M
R6, 47, 60, 84, 41 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R9, 11, 12, 16, 20 RES,100,5%,250MW,METAL FILM R-376-100
R10 RES, 332K,1%, 100MW, THICK FILM R-418-332K
R15, 17, 21, 23, 31, 70, 72, 18,
6
4
, 59, 48, 61, 8
RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R25, 28, 49 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R30, 26 RES, 100, 1%, 100MW, THICK FILM R-418-100
R33, 39 RES, .0499, 1%, 100MW, THICK FILM R-418-.0499
R38 RES, 11K, 1%, 100MW, THICK FILM R-418-11K
R40, 32, 27, 24 RES, 5.1K,5%, 125MW, METAL FILM R-375-5.1K
R43, 44, 45, 65 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R51 RES, 7.5K, 1%, 125MW, METAL FILM R-391-7.5K
R53, 54 RES, 3.01K, 1%, 100MW THICK FILM R-418-3.01K
R55 RES, 10M, 1%, 125MW, THICK FILM R-418-10M
R56 RES, 3.01K, 1%, 100MW THICK FILM R-418-3.01K
R57 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R73, 74, 76, 78-81,
83, 7, 69,71,85-89
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R77 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R82 RES, 499, 1%, 100MW THICK FILM R-418-499
R91, 92 RES, 200, 1%, 100MW, THICK FILM R-418-200
S01, 2 SOCKET PLCC-032-T-A SO-143-32
S1 SWITCH, PUSHBUTTON (6 POLE) SW-466
T1 TRANSFORMER FOR F SUPPLIES TR-302B
TP3 CONN, TEST POINT CS-553
U1, 22 IC, DUAL D-TYPE F/F, 74HC74 IC-773
U2 IC, MICROMANAGER, DS12365-10 IC-884
U3 MICROCONTROLLER, MC68332-FC LSI-161
U4 IC +5V RS-232 TRANSCEIVER, MAX202 IC-952
U5 IC, OP-AMP, AD705JR IC-814
Table 6-2 (cont.)
Dig
ita
l board parts list
Circuit designation Description Keithly part no.
Replaceable Parts 6-13
2410-902-01.book Page 13 Monday, November 7, 2005 2:49 PM
