Application Examples
2. Push Add Measurement.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors On
Screen
Configure
Cursors
3. Turn multipurpose knob a to select the
Amplitude measurement from the side menu.
If needed, press Source and turn multipurpose
knob b to select channel 1.PushOK Add
Measurement from the side menu. Repeat
this process to select channel 2 and ag ain
push OK Add Measuremen t from the side
menu.
DPO3000 Series Oscilloscopes User Manua l 233
